The Portkeys LH7H features a 7-inch touchscreen monitor with 1,000 nits of brightness, HDMI input and output ports, and a professional set of monitoring features ideal for content creators and budding filmmakers.

Note: The LH7H does not have any camera control capabilities. If you need wireless camera control, please visit the LH7P’s product page.

Custom JPG Picture Custom Freeze Frame
After capturing an image, it can be compared with real-time video by semi-transparent image superposition Note: Must be a 16:9 1920×1080 jpg image

Vertical Shooting Stretches Legs and HDMI Output
Controllable stretching of the images, Real-time monitoring the stretch effects, Stretched legs can be loaded with 3DLUT output from HDMI at 1080p60

Make All 4K Cameras Have Supersample
Supports 4K oversampling to 1080p, resulting in high resolution, high detail 1080p video

Anamorphic Lens Correction 1080p60 HDMI Output
Supported Ratio: 1.00X/1.33X/1.42X/1.50X/1.60X/1.66X/
1.85X/2.00X/2.35X
User-defined adjustment range: 0.25X-4.00X

Custom Rectangular Image Crop
Easily and clearly monitor the details of your images

Brightness and RGB Signal Detection Before/After Loading 3D LUT
Loading 3D LUTs for better picture quality and more intuitive monitoring

Basic Parameters
Screen Size: 7″
Dimension: 176.2*103.8*18.4mm
Viewing Angle: 85/85/85/85
Brightness: 1000nit
Resolution: 1920*1080
Contrast Ratio: 1000:1
Weight: 245g
Color Gamut: Rec.709
Maximum Power: 8W
Material:PC+ABS
Input Voltage: 7-24V
Fan: Quiet

Package Including:

1x LH7H Monitor

1x A to A HDMI Cable

1x Screen Cleaning Wipe

1x Safety Box

1xUSB
