Professional Color Calibration, Restore True Colors
DCl-P3 color gamut, DeltaE<1, no distortion and no color deviation to show the real image, enjoy the high-quality visual experience.

Support Custom 3D LUTs
Support 3D-LUT output to quickly present the desired shooting effect and improve the monitoring efficiency.

New UI DesignEasy and Smooth Operation
Iconization for easy touch and quick access to desired functions. Bring a smooth experience to the photographer during the shooting.

Professional Monitoring ToolsConvenient Shooting Experience
Built-in custom RGB, Filter, False color, Anamorphic ratio, Mask, and other functions.Broadcasting precision waveform monitoring for easy access to all video and audio signal information.

HDMI&SDI Dual Interface
Support LUT output and SDI input to HDMI output

Technical Parameters
MODEL NO.M7
Screen Size:7'TP
Screen Resolution: 1920*1080
Aspect Ratio: 16:9
Brightness: 2000cd/m2
Color Gamut: DCl-P3/Delta E<1
Contrast Ratio: 1800:1
Viewing Angle: 170°(HV)
Output Interface: SDI output, HDMI output,3.5mm Headphone jack
Input Interface: DC in,SDl input,HDMI input,SD card slot
Video Rec Format/LUT Format: cube file(17*17*17、33*33*33)
Audio Frequency: 48kHz
Power Supply Way: Dual NP-F/DC IN
Power input range: DC7-16V
Consumption: <10W
Upgrade method: SD Card
Lut output: HDMI&SDI Support
Body material: CNC Aluminum alloy
Color: Blue-gray
Weight: 455g
Size: 178.8*110.8*20.3/28.3mm
